- Inflate or deflate your tire automatically while staying out of harm’s way.
- Safety system on both doors to activate & deactivate the inflation/deflation of tires.
- Equipped with steel wire mesh walls to protect against large fragments from tire explosions.
- For tires of up to 78" OD X 50" wide
- Tough enough for tire pressures of up to 145 psi with its built-in automatic tire inflator.
The Automatic HD tire inflation cage 82" offers top-of-the-line protection for your employees when inflating OTR; hearthmover, mining, tractor or excavation tires. Equipped with locks and safety valve systems on each door, the Automatic HD tire inflation safety cage series exceeds OSHA standard 29 CFR 1910.177 in the U.S. In addition to its sturdiness and safeness, the 82” HD tire inflation cages offer easiness, accuracy and versatility with a plug & play automatic tire inflator that is equipped with an over pressure system.
Before using the product, please read the instructions carefully.
*Air compressor required
|Meets OSHA Standard 29 CFR 1910.177||Yes|
|Product dimensions - LxWxH (inches)||84 x 56 x 82|
|Product dimensions - LxWxH (cm)||213 x 142 x 208|
|Tire type||Truck & bus tires, OTR tire|
|Overall tire diameter - max. (inches)||78|
|Overall tire diameter - max. (cm)||199|
|Wheel width - max. (inches)||50|
|Tire width - max. (cm)||128|
|Net weight (kg)||584|
|Net weight (lb)||1288|
|Hose length (inches)||120|
|Hose length (cm)||304|
|Autocalibration||Yes, on every unit start|
|Reading accuracy (psi)||0.29|
|Air compressor required||Yes|
|Finish||Powder coated paint UV resistant - Never loses is luster|
|Package dimensions - LxWxH (cm)||231 x 170 x 226|
|Package dimensions - LxWxH (inches)||91 x 67 x 89|
Can I inflate my tire with the door open?
No, the inflation process will start only once the door is closed.
Do I need to anchor my inflation cage to the floor?
Safety standards vary by region. Verify with your local health and safety organization.
My safety sticker on my inflation cage is scratched or missing. Can I order a new one?
Yes, see our spare parts section.
Do I need an air compressor with my station?
Yes, the product does not produce compressed air.
What kind of air compressor should I use with this product?
The compressor should
have a stable air supply monitored by an air regulator (maintain a minimum air pressure fluctuation)
be equipped with an air filter to protect against water and oil contained in compressed air.
meet the minimum and maximum air inlet pressure of the inflator.
Can I use another type of chuck?
Yes, other chuck types can be used. However, the chuck type installed must be respected. In this case it is an open chuck. The chuck must also remain in place without someone holding. (clip on chuck, screw on chuck, etc.)
Can I order the inflation cage with another inflator model or can I change it?
No, our cages are designed and approved with specific inflators. Any modification would void the certification and warranty.
